T 262 Liebherr T 262 Specifications & Technical Data (2004—2026)

Weight: 156t – Standard tyres: 40R57 (E4) – Dump capacity: 119m³ – Net load: 240t – Transport length: 13.3m – Transport width: 7.4m

Rigid Dump Trucks Liebherr T 262

Visit Liebherr live at

Technical specs - T 262 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
156 t
Standard tyres
40R57 (E4)
Dump capacity
119 m³
Net load
240 t
Transport length
13.3 m
Transport width
7.4 m
Transport height
6.7 m
Turning radius outside
14.25 m
Loading height
5.9 m
Engine manuf.
Cummins
Engine type
QSK 60
Engine power
2013 kW
Displacement
60 l
No. of cylinders
16
Cylinder bore x stroke
159x190 mm

More technical details, like: steering, travel speed, model series, dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Central lubrication
No
Heated dump body
No
Tailgate
No
Aircondition
No

Download datasheets (PDF)

Liebherr T 262 FAQ

When was the Liebherr T 262 manufactured?

The Liebherr T 262 was first produced in 2004.

How much does the Liebherr T 262 rigid dump truck weigh?

The Liebherr T 262 rigid dump truck weighs 156 tons.

What are the transport dimensions of the Liebherr T 262 rigid dump truck?

The Liebherr T 262 has a transport length of 13.3 meters, a transport width of 7.4 meters, and a transport height of 6.7 meters.

What are the standard tyres used on the Liebherr T 262 rigid dump truck?

The Liebherr T 262 rigid dump truck uses 40R57 (E4) standard tyres.

What is the turning radius of the Liebherr T 262 rigid dump truck?

The Liebherr T 262 has an outside turning radius of 14.25 meters.

What is the material handling capacity of the Liebherr T 262 rigid dump truck?

The Liebherr T 262 has a net load capacity of 240 tons, a dump capacity of 119 cubic meters, and a loading height of 5.9 meters.

How much is a Liebherr T 262 Rigid dump truck (2004u20132025) worth?

The residual value of the Liebherr T 262 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
