    Liebherr T 262 Specifications & Technical Data (2004-2022)

    Rate this machine now!

    Weight: 156t – Standard tyres: 40R57 (E4) – Dump capacity: 119m³ – Net load: 240t – Transport length: 13.3m – Transport width: 7.4m

    Technical specs - T 262 Liebherr

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 156 t
    • Standard tyres 40R57 (E4)
    • Dump capacity 119 m³
    • Net load 240 t
    • Transport length 13.3 m
    • Transport width 7.4 m
    • Transport height 6.7 m
    • Turning radius outside 14.25 m
    • Loading height 5.9 m
    • Engine manuf. Cummins
    • Engine type QSK 60
    • Engine power 2013 kW
    • Displacement 60 l
    • No. of cylinders 16
    • Cylinder bore x stroke 159x190 mm

    More technical details, like: steering, travel speed , dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

    Basic model with ROPS cabin and std. trough

    Special equipment

    • Diesel particulate filter
    • Central lubrication
    • Heated dump body
    • Tailgate
    • Aircondition
