HD465-3 Komatsu HD465-3 Specifications & Technical Data (1986—1993)
Visit Komatsu live at
.jpg){kind=logo}
Technical specs - HD465-3 Komatsu
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 36.77 t
- Standard tyres
- 21.00-35-32 PR
- Dump capacity
- 34.2 m³
- Net load
- 46 t
- Steering
- KL
- Transport length
- 9 m
- Transport width
- 4.05 m
- Transport height
- 4.26 m
- Travel speed
- 70 km/h
- Turning radius outside
- 8.5 m
- Model series
- HD
- Engine manuf.
- Komatsu
- Engine type
- SAA6D170E
- Engine power
- 544 kW
- Displacement
- 23.1 l
- Revolutions at max torque
- 2100 rpm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 170x170 mm
More technical details, like: loading height, dimension lxwxh, max. torque, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
Download datasheets (PDF)
