Komatsu HD325-8E0 Specifications & Technical Data (2017-2021)

Technical specs - HD325-8E0 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 34.18 t

Standard tyres: 18.00 R 33

Dump capacity: 16.9 m³

Net load: 36.5 t

Steering: VL

Transport length: 9.245 m

Transport width: 4.86 m

Transport height: 4.365 m

Travel speed: 68 km/h

Turning radius outside: 7.2 m

Loading height: 3.26 m

Model series: HD

Engine manuf.: Komatsu

Engine type: SAA6D140E7

Engine power: 386 kW

Displacement: 15.24 l

Revolutions at max torque: 2000 rpm

Max. torque: 3.644 Nm

No. of cylinders: 6

Cylinder bore x stroke: 140x165 mm

Emission level: Euro IV

More technical details, like: dimension lxwxh, passenger seat, air conditioner, decent control, camera system available, camera system platform, telematics available, platform, engine manufacturer, engine model, aspiration, cooling...

More technical details, like: dimension lxwxh, passenger seat, air conditioner, decent control, camera system available, camera system platform, telematics available, platform, engine manufacturer, engine model, aspiration, cooling, engine output - net, engine output - gross, transmission type, drive configuration, final drive, speeds - forward, speeds - reverse, tyre size, retarder - type, length - overall, height - max, height - over canopy / rock guard rail, width - over tyres, width - transport, width - operating, wheelbase, length - body, loading height, full dump height, width - over body, hoist - angle, fuel tank, engine oil, transmission - system, body type, struck capacity, heaped capacity, retardation system - 1, gears - forward / reverse, speed - forward maximum, net weight, payload, gross weight are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: Yes
Tailgate: No
Aircondition: Yes

Download datasheets (PDF)

Komatsu HD325-8E0 FAQ

When was the Komatsu HD325-8E0 manufactured?

The Komatsu HD325-8E0 was manufactured from 2017 to 2021.

How much does the Komatsu HD325-8E0 weigh?

The Komatsu HD325-8E0 weighs 34.18 tons.

What are the transport dimensions of the Komatsu HD325-8E0 rigid dump truck?

The Komatsu HD325-8E0 has a transport length of 9.25 meters, a transport width of 4.86 meters, and a transport height of 4.37 meters.

What is the travel speed of the Komatsu HD325-8E0 rigid dump truck?

The Komatsu HD325-8E0 has a travel speed of 68 km/h.

What are the undercarriage specifications of the Komatsu HD325-8E0 rigid dump truck?

The Komatsu HD325-8E0 is equipped with standard tyres sized 18.00 R 33.

What are the maneuverability specifications of the Komatsu HD325-8E0 rigid dump truck?

The Komatsu HD325-8E0 has a front steering system and an outside turning radius of 7.2 meters.

What is the material handling capacity of the Komatsu HD325-8E0 rigid dump truck?

The Komatsu HD325-8E0 has a net load capacity of 36.5 tons, a dump capacity of 16.9 cubic meters, and a loading height of 3.26 meters.

How much is a Komatsu HD325-8E0 Rigid dump truck (2017u20132021) worth?

The residual value of the Komatsu HD325-8E0 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
