795F AC Caterpillar 795F AC Specifications & Technical Data (2009—2026)

Weight: 257.68t – Standard tyres: 56/80R63 – Dump capacity: 252m³ – Net load: 338t – Transport length: 15.15m – Transport width: 9.45m

795F AC

Years of manufacture: 2009—2026

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 795F AC Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 257.68 t

Standard tyres: 56/80R63

Dump capacity: 252 m³

Net load: 338 t

Transport length: 15.15 m

Transport width: 9.45 m

Transport height: 7.8 m

Travel speed: 64 km/h

Turning radius outside: 38.7 m

Loading height: 7.04 m

Model series: AC

Engine manuf.: Caterpillar

Engine type: C175-16

Engine power: 2536 kW

Displacement: 85 l

Cylinder bore x stroke: 175x220 mm

Emission level: Tier 2

More technical details, like: steering, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 795F AC FAQ

When was the Caterpillar 795F AC manufactured?

The Caterpillar 795F AC was first produced in 2009.

How much does the Caterpillar 795F AC weigh?

The Caterpillar 795F AC weighs 257.68 tons.

What are the transport dimensions of the Caterpillar 795F AC rigid dump truck?

The Caterpillar 795F AC has a transport length of 15.15 meters, a transport width of 9.45 meters, and a transport height of 7.8 meters.

What is the travel speed of the Caterpillar 795F AC rigid dump truck?

The Caterpillar 795F AC has a travel speed of 64 km/h.

What are the undercarriage specifications of the Caterpillar 795F AC rigid dump truck?

The Caterpillar 795F AC is equipped with standard tyres sized 56/80R63.

What is the turning radius of the Caterpillar 795F AC rigid dump truck?

The Caterpillar 795F AC has an outside turning radius of 38.7 meters.

What is the material handling capacity of the Caterpillar 795F AC rigid dump truck?

The Caterpillar 795F AC has a net load capacity of 338 tons, a dump capacity of 252 cubic meters, and a loading height of 7.04 meters.
