Technical specs - 793F Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 169.93 t
- Standard tyres
- 40.00R57
- Dump capacity
- 142 m³
- Net load
- 226.8 t
- Transport length
- 13.7 m
- Transport width
- 7.6 m
- Transport height
- 5.6 m
- Travel speed
- 60 km/h
- Loading height
- 6.53 m
- Engine manuf.
- Caterpillar
- Engine type
- C175-16
- Engine power
- 1848 kW
- Displacement
- 85 l
- Cylinder bore x stroke
- 175x220 mm
- Emission level
- Tier 4
More technical details, like: steering, turning radius outside, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
Yes
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
Download specalog and datasheets (PDF)
