Caterpillar 775G Specifications & Technical Data (2017-2026)

Technical specs - 775G Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 50.2 t

Standard tyres: 24.00R35

Dump capacity: 42.23 m³

Net load: 63.674 t

Transport length: 10.073 m

Transport width: 5.012 m

Transport height: 4.459 m

Travel speed: 67.6 km/h

Loading height: 3.963 m

Engine manuf.: Caterpillar

Engine type: C27 Acert

Engine power: 578 kW

Displacement: 27 l

Revolutions at max torque: 1200 rpm

Max. torque: 3992 Nm

Cylinder bore x stroke: 137x152 mm

Emission level: Tier 4 f

More technical details, like: steering, turning radius outside, model series, dimension lxwxh, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 775G FAQ

When was the Caterpillar 775G manufactured?

The Caterpillar 775G was first produced in 2017.

How much does the Caterpillar 775G rigid dump truck weigh?

The Caterpillar 775G rigid dump truck weighs 50.2 tons.

What are the transport dimensions of the Caterpillar 775G rigid dump truck?

The Caterpillar 775G has a transport length of 10.07 meters, a transport width of 5.01 meters, and a transport height of 4.46 meters.

What is the travel speed of the Caterpillar 775G rigid dump truck?

The Caterpillar 775G has a travel speed of 67.6 km/h.

What are the undercarriage specifications of the Caterpillar 775G rigid dump truck?

The Caterpillar 775G rigid dump truck is equipped with standard tyres sized 24.00R35.

What is the material handling capacity of the Caterpillar 775G rigid dump truck?

The Caterpillar 775G has a net load capacity of 63.67 tons, a dump capacity of 42.23 cubic meters, and a loading height of 3.96 meters.

How much is a Caterpillar 775G Rigid dump truck (2017u20132025) worth?

The residual value of the Caterpillar 775G depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
