Belaz 75602 Specifications & Technical Data (2010-2023)

Rate this machine now!

Weight: 261t – Standard tyres: 59/80R63 – Dump capacity: 218.1m³ – Net load: 360t – Steering: VL – Transport length: 15.5m

Technical specs - 75602 Belaz


Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 261 t
  • Standard tyres 59/80R63
  • Dump capacity 218.1 m³
  • Net load 360 t
  • Steering VL
  • Transport length 15.5 m
  • Transport width 9.6 m
  • Transport height 7.47 m
  • Travel speed 64 km/h
  • Turning radius outside 17.2 m
  • Loading height 6.75 m
  • Model series 7560
  • Engine manuf. MTU
  • Engine type 20V4000
  • Engine power 2796 kW
  • No. of cylinders 20

More technical details, like: average fuel consumption, fuel consumption range (min - max), dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

  • Diesel particulate filter
  • Central lubrication
  • Heated dump body
  • Tailgate
  • Aircondition
