Technical specs - RD 40 C Astra

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 30 t

Standard tyres: 18.00 R 33

Dump capacity: 18 m³

Net load: 40 t

Steering: VL

Transport length: 7.785 m

Transport width: 3.824 m

Transport height: 3.858 m

Travel speed: 47.6 km/h

Turning radius outside: 9.9 m

Loading height: 3.312 m

Model series: RD

Engine manuf.: Iveco

Engine type: Cursor 13

Engine power: 368 kW

Displacement: 12.8 l

Revolutions at max torque: 2100 rpm

Emission level: TIII

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, engine manufacturer, engine model, aspiration, engine output - gross, transmission type, drive configuration, final drive, tyre size, retarder - type, length - overall, height - max, height - over canopy / rock guard rail, ground clearance, width - over tyres, width - transport, width - operating, wheelbase, loading height, full dump height, width - over body, hoist - angle, fuel tank, engine oil, cooling system, body type, struck capacity, heaped capacity, gears - forward / reverse, speed - forward maximum, net weight, payload, gross weight are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: No

Download datasheets (PDF)

Astra RD 40 C FAQ

When was the Astra RD 40 C manufactured?

The Astra RD 40 C was manufactured from 2010 to 2015.

How much does the Astra RD 40 C weigh?

The Astra RD 40 C weighs 30 tons.

What are the transport dimensions of the Astra RD 40 C rigid dump truck?

The Astra RD 40 C has a transport length of 7.79 meters, a transport width of 3.82 meters, and a transport height of 3.86 meters.

What is the travel speed of the Astra RD 40 C rigid dump truck?

The Astra RD 40 C has a travel speed of 47.6 km/h.

What are the undercarriage specifications of the Astra RD 40 C rigid dump truck?

The Astra RD 40 C rigid dump truck is equipped with standard tyres sized 18.00 R 33.

What are the maneuverability specifications of the Astra RD 40 C rigid dump truck?

The Astra RD 40 C has a front steering system and an outside turning radius of 9.9 meters.

What is the material handling capacity of the Astra RD 40 C rigid dump truck?

The Astra RD 40 C has a net load capacity of 40 tons, a dump capacity of 18 cubic meters, and a loading height of 3.31 meters.
