EXP 5015 Solmec EXP 5015 Specifications & Technical Data (2022—2026)

Weight: 21.3t – Standard tyres: 10.00 x 20/10.00 x 20 – 16 PR – Boom: UA – Outrigger stabilisers: 22/4-fold – Transport length: 8.155m – Transport height: 3.59m

Material Handlers Solmec EXP 5015

Technical specs - EXP 5015 Solmec

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.3 t
Standard tyres
10.00 x 20/10.00 x 20 – 16 PR
Boom
UA
Outrigger stabilisers
2 2/4-fold
Transport length
8.155 m
Transport height
3.59 m
Transport width
2.52 m
Max. Reach horizontal
9.5 m
Dredging depth
3.5 m
Travel speed
17 km/h
Engine manuf.
Deutz
Engine type
TCD3.6 L4 T4
Engine power
100 kW
Displacement
3.6 l
Revolutions at max torque
1600 rpm
Max. torque
480 Nm
No. of cylinders
4
Emission level
Stage V/Tier 5

More technical details, like: tear-out force, dipper length, turning radius inside, turning radius outside, track width, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
