821M E Sennebogen 821M E Specifications & Technical Data (2018—2021)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Sennebogen live at
.jpg){kind=logo}
Technical specs - 821M E Sennebogen
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 25.1 t
- Standard tyres
- 10.00-20
- Boom
- UA
- Outrigger stabilisers
- 2/4 2/4-fold
- Transport length
- 10.4 m
- Transport height
- 3.25 m
- Transport width
- 2.5 m
- Max. Reach horizontal
- 13 m
- Travel speed
- 20 km/h
- Model series
- M
- Engine manuf.
- Cummins
- Engine type
- QSB4.5
- Engine power
- 119 kW
- Displacement
- 4.5 l
- Revolutions at max torque
- 2300 rpm
- Emission level
- IV
More technical details, like: dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Download datasheets (PDF)
Sennebogen 821M E FAQ
How much does the Sennebogen 821M E weigh?
What are the transport dimensions of the Sennebogen 821M E material handler?
What is the travel speed of the Sennebogen 821M E material handler?
What are the undercarriage specifications of the Sennebogen 821M E material handler?
What is the maximum horizontal reach and boom type of the Sennebogen 821M E?
How much is a Sennebogen 821M E Material handler (2018u20132021) worth?
