M20 Minelli M20 Specifications & Technical Data (2023—2026)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - M20 Minelli
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 20 t
- Standard tyres
- 9.00x20”
- Outrigger stabilisers
- 2 2/4-fold
- Transport length
- 8.08 m
- Transport height
- 3.16 m
- Transport width
- 2.49 m
- Max. Reach horizontal
- 9.3 m
- Travel speed
- 12 km/h
- Model series
- M
- Engine manuf.
- Perkins
- Engine type
- 904J-E36TE
- Engine power
- 90 kW
- Displacement
- 3.6 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 500 Nm
- No. of cylinders
- 4
- Emission level
- EU Stage V
More technical details, like: boom, dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Download datasheets (PDF)
Minelli M20 FAQ
How much does the Minelli M20 weigh?
What are the transport dimensions of the Minelli M20 material handler?
What is the travel speed of the Minelli M20 material handler?
What are the undercarriage specifications of the Minelli M20 material handler?
What is the maximum horizontal reach of the Minelli M20?
How much is a Minelli M20 Material handler (2023u20132025) worth?
