DX210WMH-5 Develon DX210WMH-5 Specifications & Technical Data (2023—2026)

Weight: 25.955t – Standard tyres: 10.00R20 – Boom: UA – Outrigger stabilisers: 22/4-fold – Transport length: 9.53m – Transport height: 3.58m

Material Handlers Develon DX210WMH-5

Visit Develon live at

Technical specs - DX210WMH-5 Develon

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
25.955 t
Standard tyres
10.00R20
Boom
UA
Outrigger stabilisers
2 2/4-fold
Transport length
9.53 m
Transport height
3.58 m
Transport width
2.5 m
Max. Reach horizontal
10.72 m
Dredging depth
5 m
Travel speed
35.4 km/h
Model series
DX
Engine manuf.
Develon
Engine type
DL06P
Engine power
140.9 kW
Displacement
5.9 l
Revolutions at max torque
1400 rpm
Max. torque
804 Nm
No. of cylinders
6
Cylinder bore x stroke
100x125 mm
Emission level
Tier 4

More technical details, like: tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh are available in the full technical specs.
