MH3250 Caterpillar MH3250 Specifications & Technical Data (2022—2026)
Technical specs - MH3250 Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 48.85 t
- Boom
- MB
- Transport length
- 12 m
- Transport height
- 3.57 m
- Transport width
- 4.01 m
- Max. Reach horizontal
- 16.01 m
- Dredging depth
- 7.09 m
- Tear-out force
- 246 kN
- Turning radius inside
- 3.53 m
- Travel speed
- 3.4 km/h
- Track width
- 600 mm
- Engine manuf.
- Caterpillar
- Engine type
- C9.3B
- Engine power
- 234 kW
- Displacement
- 9.3 l
- Revolutions at max torque
- 1800 rpm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 115 x 127 mm
- Emission level
- Stage V/Tier 4F
More technical details, like: standard tyres, outrigger stabilisers, dipper length, turning radius outside, model series, dimension lxwxh, max. torque are available in the full technical specs.
