4230D Liugong 4230D Specifications & Technical Data (2021—2026)

Weight: 17t – Standard tyres: 17.5-25 – Transport length: 9.09m – Transport width: 2.6m – Transport height: 3.38m – Mouldboard width: 4.27m

Graders Liugong 4230D

Visit Liugong live at

Technical specs - 4230D Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17 t
Standard tyres
17.5-25
Transport length
9.09 m
Transport width
2.6 m
Transport height
3.38 m
Mouldboard width
4.27 m
Travel speed
42 km/h
Turning radius outside
7.2 m
Model series
D
Engine manuf.
Cummins
Engine type
QSL9.3
Engine power
180 kW
Max. torque
1186 Nm
No. of cylinders
6
Emission level
Tier 3/Stage III

More technical details, like: steering mode, drive, front blade width, dimension lxwxh, displacement, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
No
Front blade
No
Rear ripper
No
Aircondition
No
