BG 180 TA-7 HBM-NOBAS BG 180 TA-7 Specifications & Technical Data (2019—2026)

Weight: 19t – Standard tyres: 17.5 R25 – Steering mode: VKL – Drive: A – Transport length: 10.285m – Transport width: 2.684m

BG 180 TA-7

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - BG 180 TA-7 HBM-NOBAS

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19 t

Standard tyres: 17.5 R25

Steering mode: VKL

Drive: A

Transport length: 10.285 m

Transport width: 2.684 m

Transport height: 3.32 m

Mouldboard width: 3.66 m

Front blade width: 2.49 m

Travel speed: 40 km/h

Turning radius outside: 8.6 m

Model series: BG

Engine manuf.: Perkins

Engine type: 1206J-E70TA

Engine power: 151 kW

Displacement: 7.01 l

Revolutions at max torque: 2200 rpm

Max. torque: 870/1400 Nm

No. of cylinders: 6

Cylinder bore x stroke: 105x135 mm

Emission level: Euro V

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: Yes
Bilateral levelling automatic: No
Front blade: Yes
Rear ripper: Yes
Aircondition: Yes

Download datasheets (PDF)

BG 180 TA-7 HBM-NOBAS Specification for Europe (DE)

HBM-NOBAS BG 180 TA-7 FAQ

When was the HBM-NOBAS BG 180 TA-7 manufactured?

The HBM-NOBAS BG 180 TA-7 was first produced in 2019.

How much does the HBM-NOBAS BG 180 TA-7 weigh?

The HBM-NOBAS BG 180 TA-7 weighs 19 tons.

What are the transport dimensions of the HBM-NOBAS BG 180 TA-7 grader?

The HBM-NOBAS BG 180 TA-7 has a transport length of 10.29 meters, a transport width of 2.68 meters, and a transport height of 3.32 meters.

What is the travel speed of the HBM-NOBAS BG 180 TA-7 grader?

The HBM-NOBAS BG 180 TA-7 grader has a travel speed of 40 km/h.

What are the undercarriage specifications of the HBM-NOBAS BG 180 TA-7 grader?

The HBM-NOBAS BG 180 TA-7 grader features an all-wheel drive system and standard tyres sized 17.5 R25.

What are the maneuverability specifications of the HBM-NOBAS BG 180 TA-7 grader?

The HBM-NOBAS BG 180 TA-7 has an outside turning radius of 8.6 meters and features front and articulated-frame steering.

What are the primary blade specifications of the HBM-NOBAS BG 180 TA-7 grader?

The HBM-NOBAS BG 180 TA-7 grader has a front blade width of 2.49 meters and a mouldboard width of 3.66 meters.
