Weight: 73.34t – Standard tyres: 29.5R29 – Transport length: 16.71m – Transport width: 4.43m – Transport height: 4m – Mouldboard width: 7m

Years of manufacture: 2017—2026

Data sheet
Spare parts
Transport
News

Technical specs - 24 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 73.34 t

Standard tyres: 29.5R29

Transport length: 16.71 m

Transport width: 4.43 m

Transport height: 4 m

Mouldboard width: 7 m

Travel speed: 41.9 km/h

Turning radius outside: 12.5 m

Engine manuf.: Caterpillar

Engine type: C27 Acert

Engine power: 399 kW

Displacement: 27 l

Max. torque: 3277 Nm

No. of cylinders: 12

Cylinder bore x stroke: 137.2 x 152.4 mm

Emission level: Tier 4f. IV

More technical details, like: steering mode, drive, front blade width, model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 24 FAQ

When was the Caterpillar 24 manufactured?

The Caterpillar 24 was first produced in 2017.

How much does the Caterpillar 24 grader weigh?

The Caterpillar 24 grader weighs 73.34 tons.

What are the transport dimensions of the Caterpillar 24 grader?

The Caterpillar 24 grader has a transport length of 16.71 meters, a transport width of 4.43 meters, and a transport height of 4 meters.

What is the travel speed of the Caterpillar 24 grader?

The Caterpillar 24 grader has a travel speed of 41.9 km/h.

What are the undercarriage tyre specifications of the Caterpillar 24 grader?

The Caterpillar 24 grader is equipped with standard tyres sized 29.5R29.

What is the turning radius of the Caterpillar 24 grader?

The Caterpillar 24 grader has an outside turning radius of 12.5 meters.

What is the mouldboard width of the Caterpillar 24 grader?

The Caterpillar 24 grader has a mouldboard width of 7 meters.

How much is a Caterpillar 24 Grader (2017u20132025) worth?

The residual value of the Caterpillar 24 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Caterpillar 24 overview

Caterpillar 24 features overview

Serviceability

The improved power train rebuild life, new modular design and new machine protection features can save you up to 2,400 servicing hours over the life of the machine. The Cat C27 ACERT engine, 533 mm (21 in) transmission, and lower power train provide 33 percent additional machine life before needing to be rebuilt. Additionally, the new, innovative main component modular design means they can be removed and installed quicker and easier. The transmission and cooling package can be removed up to 70 percent faster than the 24M. The Fluid Service Center provides a single location at ground level for access to the engine, transmission, hydraulic oil, and coolant. This feature, along with clustered filters and extended service intervals, saves you maintenance time and operating costs. Furthermore, hoses and electrical harnesses are split at easily accessible bulkhead locations, allowing your service technicians to work with smaller sections easier and faster. The Ok-to-Start and Critically Low Fluid monitoring systems protect your machine by providing electronic verification of fluid levels and alerting you when low fluid levels are detected, thus protecting your machine.

Engine / powertrain

Standards

The dynamic spectator sound power level is 112 dB(A) for Tier 4/Stage IV certified configurations and 113 dB(A) for equivalent Tier 2/Stage II configurations when measured according to the dynamic test procedures that are specified in ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed. The machine was equipped with a sound suppression system. The dynamic operator sound pressure level is 77 dB(A) for Tier 4/Stage IV certified configurations and 73 dB(A) for equivalent Tier 2/Stage II configurations when measured according to the dynamic test procedures that are specified in ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed, with the cab doors and the cab windows closed. The cab was properly installed and maintained. The machine was equipped with a sound suppression system.
