Technical specs - 160M AWD (Environment Canada Tier 3) Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 20.61 t

Standard tyres: 14.00R24

Steering mode: VKL

Drive: A

Transport length: 8.75 m

Transport width: 2.59 m

Transport height: 3.31 m

Mouldboard width: 3.7 m

Travel speed: 47.4 km/h

Turning radius outside: 7.6 m

Engine manuf.: Caterpillar

Engine type: C9 Acert

Engine power: 200 kW

Displacement: 8.8 l

Revolutions at max torque: 1000 rpm

Max. torque: 1344 Nm

No. of cylinders: 6

Cylinder bore x stroke: 112x149 mm

Emission level: Environment Canada Tier 3

More technical details, like: front blade width, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

160M AWD (Environment Canada Tier 3) Caterpillar Specification for Europe (EN)

Caterpillar 160M AWD (Environment Canada Tier 3) FAQ

When was the Caterpillar 160M AWD (Environment Canada Tier 3) manufactured?

The Caterpillar 160M AWD (Environment Canada Tier 3) was manufactured from 2017 to 2019.

How much does the Caterpillar 160M AWD (Environment Canada Tier 3) weigh?

The Caterpillar 160M AWD (Environment Canada Tier 3) weighs 20.61 tons.

What are the transport dimensions of the Caterpillar 160M AWD (Environment Canada Tier 3)?

The transport dimensions of the Caterpillar 160M AWD (Environment Canada Tier 3) are 8.75 meters in length, 2.59 meters in width, and 3.31 meters in height.

What is the travel speed of the Caterpillar 160M AWD (Environment Canada Tier 3)?

The Caterpillar 160M AWD (Environment Canada Tier 3) has a travel speed of 47.4 km/h.

What are the undercarriage specifications of the Caterpillar 160M AWD (Environment Canada Tier 3)?

The Caterpillar 160M AWD (Environment Canada Tier 3) features an all-wheel drive system and uses standard tyres sized 14.00R24.

What are the maneuverability specifications of the Caterpillar 160M AWD (Environment Canada Tier 3) grader?

The Caterpillar 160M AWD (Environment Canada Tier 3) grader has an outside turning radius of 7.6 meters and features front and articulated-frame steering.

What is the mouldboard width of the Caterpillar 160M AWD (Environment Canada Tier 3) grader?

The mouldboard width of the Caterpillar 160M AWD (Environment Canada Tier 3) grader is 3.7 meters.
