Technical specs - 160M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19.71 t

Standard tyres: 14.00R24

Steering mode: VKL

Drive: A

Transport length: 8.75 m

Transport width: 2.51 m

Transport height: 3.31 m

Mouldboard width: 3.7 m

Travel speed: 47.4 km/h

Turning radius outside: 7.6 m

Engine manuf.: Caterpillar

Engine type: C9 Acert

Engine power: 185 kW

Displacement: 8.8 l

Revolutions at max torque: 1000 rpm

Max. torque: 1237 Nm

No. of cylinders: 6

Cylinder bore x stroke: 112x149 mm

Emission level: Tier 3 / EU IIIA

More technical details, like: front blade width, model series, dimension lxwxh are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: No
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 160M FAQ

When was the Caterpillar 160M manufactured?

The Caterpillar 160M was manufactured from 2017 to 2019.

How much does the Caterpillar 160M grader weigh?

The Caterpillar 160M grader weighs 19.71 tons.

What are the transport dimensions of the Caterpillar 160M grader?

The Caterpillar 160M grader has a transport length of 8.75 meters, a transport width of 2.51 meters, and a transport height of 3.31 meters.

What is the travel speed of the Caterpillar 160M grader?

The Caterpillar 160M grader has a travel speed of 47.4 km/h.

What are the undercarriage specifications of the Caterpillar 160M grader?

The Caterpillar 160M grader has an all-wheel drive system and uses standard tyres sized 14.00R24.

What are the maneuverability specifications of the Caterpillar 160M grader?

The Caterpillar 160M grader has a turning radius of 7.6 meters and features front and articulated-frame steering.

What is the mouldboard width of the Caterpillar 160M grader?

The Caterpillar 160M grader has a mouldboard width of 3.7 meters.
