14M3 Caterpillar 14M3 Specifications & Technical Data (2017—2026)

Weight: 25.97t – Standard tyres: 20.5 R25 – Transport length: 9.6m – Transport width: 3.05m – Transport height: 3.57m – Mouldboard width: 4.3m

14M3

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 14M3 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 25.97 t

Standard tyres: 20.5 R25

Transport length: 9.6 m

Transport width: 3.05 m

Transport height: 3.57 m

Mouldboard width: 4.3 m

Travel speed: 50.5 km/h

Turning radius outside: 8 m

Engine manuf.: Caterpillar

Engine type: C13 Acert VHP

Engine power: 178 kW

Displacement: 12.5 l

Max. torque: 1542 Nm

No. of cylinders: 6

Cylinder bore x stroke: 130 x 157 mm

Emission level: Tier 4. IV

More technical details, like: steering mode, drive, front blade width, model series, dimension lxwxh, revolutions at max torque are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter: Yes
Bilateral levelling automatic: No
Front blade: No
Rear ripper: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 14M3 FAQ

When was the Caterpillar 14M3 manufactured?

The Caterpillar 14M3 was first produced in 2017.

How much does the Caterpillar 14M3 grader weigh?

The Caterpillar 14M3 grader weighs 25.97 tons.

What are the transport dimensions of the Caterpillar 14M3 grader?

The Caterpillar 14M3 grader has a transport length of 9.6 meters, a transport width of 3.05 meters, and a transport height of 3.57 meters.

What is the travel speed of the Caterpillar 14M3 grader?

The Caterpillar 14M3 grader has a travel speed of 50.5 km/h.

What are the standard tyres of the Caterpillar 14M3 grader?

The Caterpillar 14M3 grader is equipped with standard tyres sized 20.5 R25.

What is the turning radius of the Caterpillar 14M3 grader?

The Caterpillar 14M3 grader has an outside turning radius of 8 meters.

What is the mouldboard width of the Caterpillar 14M3 grader?

The mouldboard width of the Caterpillar 14M3 grader is 4.3 meters.

How much is a Caterpillar 14M3 Grader (2017u20132025) worth?

The residual value of the Caterpillar 14M3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
