Technical specs - 865B Case
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 15.85 t
- Standard tyres
- 17.5 X 25 12P - L2
- Drive
- A
- Transport length
- 8.534 m
- Transport width
- 3.962 m
- Transport height
- 3.34 m
- Front blade width
- 3.962 m
- Travel speed
- 44.1 km/h
- Turning radius outside
- 7.25 m
- Model series
- B
- Engine manuf.
- FPT
- Engine type
- F 4 HE 9687 C
- Engine power
- 142 kW
- Displacement
- 6.7 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 880 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 104x132 mm
- Emission level
- Tier 3
More technical details, like: steering mode, mouldboard width, dimension lxwxh are available in the full technical specs.
Basic model with ROPS cabin and central blade
Special equipment
- Diesel particulate filter
-
No
- Bilateral levelling automatic
-
No
- Front blade
-
No
- Rear ripper
-
No
- Aircondition
-
No
Download datasheets (PDF)
