    Technical specs - W 120 Ri Wirtgen

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    Weight 14.8 t
    Standard tyres 620x230 / 620x255
    Cutting width 1200 mm
    Cutting depth 300 mm
    Operating speed 33 m/min
    Travel speed 7,5 km/h
    Transport length 4.75 m
    Transport width 2.49 m
    Transport height 3.67 m
    Engine manuf. Deutz
    Engine type TCD6.1 L6
    Engine power 160 kW
    Engine power 218 HP
    Displacement 6.057 l
    Emission level Euro V / US Tier 4f
    Track width ###
    Turning radius outside ###
    Dimension lxwxh ###
    Revolutions at max torque ###
    Max. torque ###
    No. of cylinders ###
    Cylinder bore x stroke ###
    Weight ###

    Basic model with cutting tools

    W 120 Ri Wirtgen - Special equipment

    • Diesel particulate filter
    • Cabin
    • Front loading conveyor
    • Infrared heater
    • Aircondition
