Caterpillar PM310 Specifications & Technical Data (2019-2024)

Rate this machine now!

Weight: 20.04t – Cutting width: 1000mm – Cutting depth: 330mm – Operating speed: 33m/min – Travel speed: 5.5km/h – Transport length: 9.32m

Technical specs - PM310 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 20.04 t
  • Cutting width 1000 mm
  • Cutting depth 330 mm
  • Operating speed 33 m/min
  • Travel speed 5.5 km/h
  • Transport length 9.32 m
  • Transport width 2.55 m
  • Transport height 3 m
  • Model series PM
  • Engine manuf. Caterpillar
  • Engine type C9.3 Acert
  • Engine power 242 kW
  • Emission level Tier 4 f / IV

More technical details, like: track width, standard tyres, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with cutting tools

Special equipment

  • Diesel particulate filter
  • Cabin
  • Front loading conveyor
  • Infrared heater
  • Aircondition
