Caterpillar PM102
- Weight:
- 16.4 t
- Cutting width:
- 1000 mm
- Cutting depth:
- 305 mm
- Turning radius outside:
- 3.45 m
PM102 Caterpillar PM102 Specifications & Technical Data (2017—2026)
.jpeg)
.jpeg)
.jpeg)
.jpeg)
.jpeg)
.jpeg)
Technical specs - PM102 Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 16.4 t
- Cutting width
- 1000 mm
- Cutting depth
- 305 mm
- Turning radius outside
- 3.45 m
- Operating speed
- 27 m/min
- Travel speed
- 6.4 km/h
- Transport length
- 8.5 m
- Transport width
- 2 m
- Transport height
- 3.1 m
- Model series
- PM
- Engine manuf.
- Caterpillar
- Engine type
- C7 Acert
- Engine power
- 168 kW
- Displacement
- 7.2 l
More technical details, like: track width, standard tyres, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with cutting tools
Special equipment
- Diesel particulate filter
-
No
- Cabin
-
No
- Front loading conveyor
-
No
- Infrared heater
-
No
- Aircondition
-
No
