Bitelli SF 101 R
- Weight:
- 14.9 t
- Standard tyres:
- VR 260 / HR 305
- Cutting width:
- 1000 mm
- Cutting depth:
- 250 mm
SF 101 R Bitelli SF 101 R Specifications & Technical Data (1998—2010)
-
Model rating
- 7,50 / 10
Technical specs - SF 101 R Bitelli
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 14.9 t
- Standard tyres
- VR 260 / HR 305
- Cutting width
- 1000 mm
- Cutting depth
- 250 mm
- Operating speed
- 30 m/min
- Travel speed
- 6 km/h
- Transport length
- 10.4 m
- Transport width
- 1.8 m
- Transport height
- 2.66 m
- Model series
- SF
- Engine manuf.
- Deutz
- Engine type
- BF6M1013C
- Engine power
- 141 kW
- Displacement
- 7.146 l
- Revolutions at max torque
- 2300 rpm
More technical details, like: track width, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with cutting tools
Special equipment
- Diesel particulate filter
-
No
- Cabin
-
No
- Front loading conveyor
-
No
- Infrared heater
-
No
- Aircondition
-
No
