Sinomach GTY220 Specifications & Technical Data (2022-2024)

Rate this machine now!

Weight: 23.5t – Transport length: 5.46m – Transport width: 3.725m – Transport height: 3.395m – Track width: 560mm – Travel speed: 11.2km/h

Technical specs - GTY220 Sinomach

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

  • Weight 23.5 t
  • Transport length 5.46 m
  • Transport width 3.725 m
  • Transport height 3.395 m
  • Track width 560 mm
  • Travel speed 11.2 km/h
  • Reverse travel speed 13.2 km/h
  • Front blade width 3.725 m
  • Engine manuf. Cummins
  • Engine type NT855-C280S10
  • Engine power 162 kW
  • Displacement 14.01 l
  • Revolutions at max torque 1800 rpm
  • Max. torque 1030 Nm
  • No. of cylinders 6
  • Cylinder bore x stroke 139.7x152.4 mm

More technical details, like: blade type, soil pressure, transmission type, max. drawbar pull, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin and corresponding blade

Special equipment

  • Diesel particulate filter
  • Rear ripper
  • Tilt device
  • Aircondition
