D155AX-8 WH Komatsu D155AX-8 WH Specifications & Technical Data (2023—2026)
Visit Komatsu live at
.jpg){kind=logo}
Technical specs - D155AX-8 WH Komatsu
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 42.828 t
- Transport length
- 8.42 m
- Transport height
- 3.39 m
- Soil pressure
- 0.82 kg/cm²
- Track width
- 710 mm
- Travel speed
- 11.6 km/h
- Reverse travel speed
- 14 km/h
- max. Drawbar Pull
- 61 t
- Model series
- D
- Engine manuf.
- Komatsu
- Engine type
- SAA6D140E-7
- Engine power
- 268 kW
- Displacement
- 15.24 l
- Revolutions at max torque
- 1900 rpm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 140x165 mm
- Emission level
- Tier 4 Final
More technical details, like: transport width, blade type, front blade width, transmission type, dimension lxwxh, max. torque are available in the full technical specs.
Basic model with ROPS cabin and corresponding blade
Special equipment
- Diesel particulate filter
-
Yes
- Rear ripper
-
Yes
- Tilt device
-
Yes
- Aircondition
-
Yes
Download datasheets (PDF)
Komatsu D155AX-8 WH FAQ
How much does the Komatsu D155AX-8 WH weigh?
What are the transport dimensions of the Komatsu D155AX-8 WH bulldozer?
What are the travel speeds of the Komatsu D155AX-8 WH bulldozer?
What are the undercarriage specifications of the Komatsu D155AX-8 WH bulldozer?
What is the maximum drawbar pull of the Komatsu D155AX-8 WH bulldozer?
How much is a Komatsu D155AX-8 WH Bulldozer (2023u20132025) worth?
