    John Deere Construction 950K Specifications & Technical Data (2017-2022)

    Rate this machine now!

    Weight: 29.61t – Transport length: 6.39m – Transport width: 3.91m – Transport height: 3.43m – Blade type: S – Soil pressure: 0.75kg/cm²

    Technical specs - 950K John Deere Construction

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 29.61 t
    • Transport length 6.39 m
    • Transport width 3.91 m
    • Transport height 3.43 m
    • Blade type S
    • Soil pressure 0.75 kg/cm²
    • Track width 610 mm
    • Travel speed 11 km/h
    • Reverse travel speed 11 km/h
    • Front blade width 3.91 m
    • Transmission type HY
    • max. Drawbar Pull 55.78 t
    • Engine manuf. John Deere
    • Engine type PowerTech PSS 6090
    • Engine power 198 kW
    • Displacement 9 l
    • Revolutions at max torque 1800 rpm
    • Max. torque 1245/1300 Nm
    • No. of cylinders 6
    • Emission level Tier 4f/EU IV
    • Dimension lxwxh ###
    • Cylinder bore x stroke ###

    Basic model with ROPS cabin and corresponding blade

    Special equipment

    • Diesel particulate filter
    • Rear ripper
    • Tilt device
    • Aircondition
