Fiat Kobelco D 180 XLT Specifications & Technical Data (2002-2005)

Technical specs - D 180 XLT Fiat Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 21 t

Transport length: 4.21 m

Transport width: 2 m

Transport height: 3 m

Blade type: SU

Soil pressure: 0.579 kg/cm²

Track width: 560 mm

Travel speed: 12.7 km/h

Front blade width: 4 m

Engine manuf.: Cummins

Engine type: 6CT8.3

Engine power: 134 kW

Displacement: 8.3 l

Revolutions at max torque: 2000 rpm

More technical details, like: reverse travel speed, transmission type, max. drawbar pull, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, engine manufacturer, engine model...

More technical details, like: reverse travel speed, transmission type, max. drawbar pull, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, undercarriage type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, carrier rollers, track rollers, raised sprocket, shoe - width, shoe - type, number of shoes, service brake type, height - max, height - top of rops, ground clearance, width - over tracks, track length - on ground, length - no blade, blade, blade - width, blade - height, blade - dig depth, blade - lift clearance, blade - tilt, steering - differential, steering - clutches and brakes, fuel tank, blade - capacity, ground bearing pressure, implement pump - flow, implement pump - pressure, operating weight are available in the full technical specs.

Basic model with ROPS cabin and corresponding blade

Special equipment

Diesel particulate filter: No
Rear ripper: No
Tilt device: Yes
Aircondition: Yes

Download datasheets (PDF)

D 180 XLT Fiat Kobelco Specification for Europe (DE)

Fiat Kobelco D 180 XLT FAQ

When was the Fiat Kobelco D 180 XLT manufactured?

The Fiat Kobelco D 180 XLT was manufactured from 2002 to 2005.

How much does the Fiat Kobelco D 180 XLT weigh?

The Fiat Kobelco D 180 XLT weighs 21 tons.

What are the transport dimensions of the Fiat Kobelco D 180 XLT bulldozer?

The Fiat Kobelco D 180 XLT has a transport length of 4.21 meters, a transport width of 2 meters, and a transport height of 3 meters.

What is the travel speed of the Fiat Kobelco D 180 XLT bulldozer?

The Fiat Kobelco D 180 XLT bulldozer has a travel speed of 12.7 km/h.

What are the undercarriage specifications of the Fiat Kobelco D 180 XLT?

The Fiat Kobelco D 180 XLT has a track width of 560 mm and a soil pressure of 0.579 kg/cmu00b2.

What are the specifications of the primary work tool blade on the Fiat Kobelco D 180 XLT?

The Fiat Kobelco D 180 XLT is equipped with a Semi-U-blade that has a front blade width of 4 meters.

How much is a Fiat Kobelco D 180 XLT Bulldozer (2002u20132005) worth?

The residual value of the Fiat Kobelco D 180 XLT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
