Technical specs - D9T Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 48.36 t
- Transport length
- 8.23 m
- Transport width
- 2.88 m
- Transport height
- 4 m
- Blade type
- SU
- Track width
- 610 mm
- Travel speed
- 11.7 km/h
- Reverse travel speed
- 14.3 km/h
- Front blade width
- 4.31 m
- Transmission type
- HY
- Model series
- D
- Engine manuf.
- Caterpillar
- Engine type
- C18 Acert
- Engine power
- 343 kW
- Displacement
- 18.1 l
- Cylinder bore x stroke
- 145x183 mm
- Emission level
- Tier 4 F/ IV
More technical details, like: soil pressure, max. drawbar pull, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.
Basic model with ROPS cabin and corresponding blade
Special equipment
- Diesel particulate filter
-
No
- Rear ripper
-
No
- Tilt device
-
No
- Aircondition
-
Yes
Download specalog and datasheets (PDF)
