D8R LGP Caterpillar D8R LGP Specifications & Technical Data (2019—2026)

Weight: 29.3t – Transport length: 4.55m – Transport width: 3.38m – Transport height: 3.48m – Blade type: SU – Track width: 965mm

D8R LGP

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D8R LGP Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 29.3 t

Transport length: 4.55 m

Transport width: 3.38 m

Transport height: 3.48 m

Blade type: SU

Track width: 965 mm

Travel speed: 10.8 km/h

Reverse travel speed: 13.9 km/h

Front blade width: 3.94 m

Transmission type: LS

Model series: D

Engine manuf.: Caterpillar

Engine type: 3406 C-DITA

Engine power: 226 kW

Displacement: 14.6 l

Cylinder bore x stroke: 137x165 mm

Emission level: Tier 1/ I

More technical details, like: soil pressure, max. drawbar pull, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin and corresponding blade

Special equipment

Diesel particulate filter: No
Rear ripper: Yes
Tilt device: No
Aircondition: Yes

Download specalog and datasheets (PDF)

D8R LGP Caterpillar Specification for Europe (EN)

Caterpillar D8R LGP FAQ

When was the Caterpillar D8R LGP manufactured?

The Caterpillar D8R LGP was first produced in 2019.

How much does the Caterpillar D8R LGP weigh?

The Caterpillar D8R LGP weighs 29.3 tons.

What are the transport dimensions of the Caterpillar D8R LGP bulldozer?

The Caterpillar D8R LGP bulldozer has a transport length of 4.55 meters, a transport width of 3.38 meters, and a transport height of 3.48 meters.

What are the travel speeds of the Caterpillar D8R LGP bulldozer?

The Caterpillar D8R LGP bulldozer has a forward travel speed of 10.8 km/h and a reverse travel speed of 13.9 km/h.

What is the track width of the undercarriage on the Caterpillar D8R LGP?

The Caterpillar D8R LGP has a track width of 965 mm on its undercarriage.

Are there any power ratings available for the Caterpillar D8R LGP?

No power rating data is available for the Caterpillar D8R LGP.

What are the specifications of the primary work tool on the Caterpillar D8R LGP bulldozer?

The Caterpillar D8R LGP bulldozer is equipped with a semi-U-blade that has a front blade width of 3.94 meters.

How much is a Caterpillar D8R LGP Bulldozer (2019u20132025) worth?

The residual value of the Caterpillar D8R LGP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
