D6T WH Caterpillar D6T WH Specifications & Technical Data (2017—2019)
Technical specs - D6T WH Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 25.43 t
- Transport length
- 5.26 m
- Transport width
- 3.201 m
- Transport height
- 3.53 m
- Soil pressure
- 0.39 kg/cm²
- Travel speed
- 11.61 km/h
- Reverse travel speed
- 11.66 km/h
- Front blade width
- 4.063 m
- Transmission type
- HY
- max. Drawbar Pull
- 40.7 t
- Model series
- D
- Engine manuf.
- Caterpillar
- Engine type
- C9.3 Acert
- Engine power
- 187 kW
- Displacement
- 9.3 l
More technical details, like: blade type, track width, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and corresponding blade
Special equipment
- Diesel particulate filter
-
No
- Rear ripper
-
No
- Tilt device
-
No
- Aircondition
-
Yes
Download specalog and datasheets (PDF)
