Caterpillar D6T LGP Specifications & Technical Data (2019-2026)

Technical specs - D6T LGP Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 22.04 t

Transport length: 3.43 m

Transport width: 3.48 m

Transport height: 3.24 m

Blade type: S

Travel speed: 11.4 km/h

Reverse travel speed: 14.6 km/h

Front blade width: 4.06 m

Transmission type: LS

Model series: D

Engine manuf.: Caterpillar

Engine type: C9 Acert

Engine power: 149 kW

Displacement: 8.8 l

Cylinder bore x stroke: 112x149 mm

Emission level: Tier 3/ IIIA

More technical details, like: soil pressure, track width, max. drawbar pull, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin and corresponding blade

Special equipment

Diesel particulate filter: No
Rear ripper: Yes
Tilt device: No
Aircondition: Yes

Download specalog and datasheets (PDF)

D6T LGP Caterpillar Specification for Latin America (EN)

Caterpillar D6T LGP FAQ

When was the Caterpillar D6T LGP manufactured?

The Caterpillar D6T LGP was first produced in 2019.

How much does the Caterpillar D6T LGP weigh?

The Caterpillar D6T LGP weighs 22.04 tons.

What are the transport dimensions of the Caterpillar D6T LGP bulldozer?

The Caterpillar D6T LGP bulldozer has a transport length of 3.43 meters, a transport width of 3.48 meters, and a transport height of 3.24 meters.

What are the travel and reverse travel speeds of the Caterpillar D6T LGP bulldozer?

The Caterpillar D6T LGP bulldozer has a travel speed of 11.4 km/h and a reverse travel speed of 14.6 km/h.

What are the power ratings of the Caterpillar D6T LGP?

The available data does not include power ratings for the Caterpillar D6T LGP.

What are the specifications of the primary work tool on the Caterpillar D6T LGP?

The Caterpillar D6T LGP is equipped with an angling blade that has a front blade width of 4.06 meters.
