Technical specs - D11T CD Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Weight 112.72 t
- Transport length 10.71 m
- Transport width 3.81 m
- Transport height 4.72 m
- Track width 915 mm
- Travel speed 11.8 km/h
- Reverse travel speed 14 km/h
- Front blade width 6.71 m
- Transmission type HY
- Engine manuf. Caterpillar
- Engine type C32 Acert
- Engine power 681 kW
- Displacement 32.1 l
- Cylinder bore x stroke 145x162 mm
- Emission level Tier 4 f
More technical details, like: blade type, soil pressure, max. drawbar pull, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.
Basic model with ROPS cabin and corresponding blade
Special equipment
- Diesel particulate filter
- Rear ripper
- Tilt device
- Aircondition
