6.23 B Venieri 6.23 B Specifications & Technical Data (2006—2016)

The Venieri 6.23 B is a backhoe loader manufactured by Venieri from 2006 to 2016. It has a weight of 7.4 tons and a transport leng…

The Venieri 6.23 B is a backhoe loader manufactured by Venieri from 2006 to 2016. It has a weight of 7.4 tons and a transport length of 5.6 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 45 kilonewtons. It can dredge up to a depth of 4.3 meters and has a bucket width of 2.1 meters. The maximum discharge height is 3.1 meters, and it has a maximum reach horizontal of 5.67 meters. The backhoe loader has a transport width of 2.1 meters and a transport height of 3.3 meters. It is equipped with special equipment including a clamshell, forklift utility, and outrigger stabilizers.

6.23 B

Years of manufacture: 2006—2016

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 6.23 B Venieri

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.4 t

Standard tyres: 14.5-20 14 PR

Bucket width: 2.1 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.6 m

Transport width: 2.1 m

Transport height: 3.3 m

Tear-out force: 45 kN

Max. Reach horizontal: 5.67 m

Dredging depth: 4.3 m

Max. discharge height: 3.1 m

Engine manuf.: Perkins

Engine type: 804D-33T

Engine power: 65 kW

Displacement: 3.331 l

Revolutions at max torque: 2600 rpm

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - net, engine output - gross, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, dig depth - sae retracted dipper, dig depth - sae extended dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: Yes
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Venieri 6.23 B FAQ

When was the Venieri 6.23 B manufactured?

The Venieri 6.23 B was manufactured from 2006 to 2016.

How much does the Venieri 6.23 B backhoe loader weigh?

The Venieri 6.23 B backhoe loader weighs 7.4 tons.

What are the transport dimensions of the Venieri 6.23 B backhoe loader?

The Venieri 6.23 B has a transport length of 5.6 meters, a transport width of 2.1 meters, and a transport height of 3.3 meters.

What are the undercarriage specifications of the Venieri 6.23 B backhoe loader?

The Venieri 6.23 B backhoe loader has an all-wheel drive and is equipped with standard tyres sized 14.5-20 14 PR.

What is the excavation performance of the Venieri 6.23 B backhoe loader?

The Venieri 6.23 B backhoe loader has a dredging depth of 4.3 meters and a maximum horizontal reach of 5.67 meters.

What is the tear-out force of the Venieri 6.23 B backhoe loader?

The Venieri 6.23 B backhoe loader has a tear-out force of 45 kN.

What is the maximum discharge height for material handling of the Venieri 6.23 B backhoe loader?

The Venieri 6.23 B backhoe loader has a maximum discharge height of 3.1 meters.

What are the specifications of the primary work tool on the Venieri 6.23 B backhoe loader?

The primary work tool of the Venieri 6.23 B backhoe loader has a bucket capacity of 1 cubic meter and a bucket width of 2.1 meters.

How much is a Venieri 6.23 B Backhoe loader (2006u20132016) worth?

The residual value of the Venieri 6.23 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
