TX650 Terex TX650 Specifications & Technical Data (2002—2023)

The Terex TX650 is a backhoe loader manufactured by Terex since 2002. It has a weight of 4.794 tons and a transport length of 4.65…

The Terex TX650 is a backhoe loader manufactured by Terex since 2002. It has a weight of 4.794 tons and a transport length of 4.65 meters. The bucket capacity is 0.9 cubic meters, with a bucket width of 2.13 meters. The maximum discharge height is 4.16 meters, and it has a travel speed of 30.1 kilometers per hour. The transport width and height are both 2.13 and 2.44 meters respectively.

Backhoe Loaders Terex TX650

Technical specs - TX650 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.794 t
Standard tyres
16.9X24
Bucket width
2.13 m
Bucket capacity
0.9 m³
Drive
A
Transport length
4.65 m
Transport width
2.13 m
Transport height
2.44 m
Max. discharge height
4.16 m
Travel speed
30.1 km/h
Engine manuf.
Perkins
Engine type
1004-40T
Engine power
59 kW
Displacement
3.9 l
Revolutions at max torque
1400 rpm
Max. torque
375 Nm
No. of cylinders
4
Cylinder bore x stroke
100x127 mm

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, dredging depth, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
No
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

Terex TX650 FAQ

When was the Terex TX650 manufactured?

The Terex TX650 was manufactured from 2002 until 2023.

How much does the Terex TX650 backhoe loader weigh?

The Terex TX650 backhoe loader weighs 4.79 tons.

What are the transport dimensions of the Terex TX650 backhoe loader?

The Terex TX650 has a transport length of 4.65 meters, a transport width of 2.13 meters, and a transport height of 2.44 meters.

What is the travel speed of the Terex TX650 backhoe loader?

The Terex TX650 backhoe loader has a travel speed of 30.1 km/h.

What are the undercarriage specifications of the Terex TX650 backhoe loader?

The Terex TX650 backhoe loader has an all-wheel drive system and is equipped with standard tyres sized 16.9X24.

What is the material handling capacity of the Terex TX650 in terms of maximum discharge height?

The Terex TX650 has a maximum discharge height of 4.16 meters.

What are the bucket specifications of the Terex TX650 backhoe loader?

The Terex TX650 backhoe loader has a bucket capacity of 0.9 cubic meters and a bucket width of 2.13 meters.
