TLB 890 Terex TLB 890 Specifications & Technical Data (2012—2017)

The Terex TLB 890 is a backhoe loader manufactured by Terex from 2012 to 2017. It has a weight of 8.15 tons and a transport length…

The Terex TLB 890 is a backhoe loader manufactured by Terex from 2012 to 2017. It has a weight of 8.15 tons and a transport length of 6.22 meters. The bucket capacity is 1 cubic meter, and it has a dredging depth of 4.5 meters. The bucket width is 2.3 meters, and the maximum discharge height is 3.58 meters. The maximum reach horizontal is 5.7 meters. The transport width is 2.11 meters, and the transport height is 3.76 meters. It is equipped with outrigger stabilizers.

TLB 890

Years of manufacture: 2012—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Reviews
Transport
News

Technical specs - TLB 890 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.15 t

Standard tyres: VR 20

Bucket width: 2.3 m

Bucket capacity: 1 m³

Drive: A

Transport length: 6.22 m

Transport width: 2.11 m

Transport height: 3.76 m

Max. Reach horizontal: 5.7 m

Dredging depth: 4.5 m

Max. discharge height: 3.58 m

Model series: TLB

Engine manuf.: Perkins

Engine type: 1104D-44TA

Engine power: 74.5 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

Max. torque: 410/1400 Nm

No. of cylinders: 4

Cylinder bore x stroke: 105x127 mm

Emission level: III A / Tier 3

More technical details, like: bucket capacity backhoe, tear-out force, tear-out force backhoe, travel speed, dimension lxwxh, backhoe type, engine manufacturer, engine model, emission rating, aspiration, charged air cooling, rated speed, engine output - net, engine output - gross, torque rated speed, torque, transmission type, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, maximum dig depth - longest dipper, dig depth - sae, dig depth - sae retracted dipper, dig depth - sae extended dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Terex TLB 890 FAQ

When was the Terex TLB 890 manufactured?

The Terex TLB 890 was manufactured from 2012 to 2017.

How much does the Terex TLB 890 backhoe loader weigh?

The Terex TLB 890 backhoe loader weighs 8.15 tons.

What are the transport dimensions of the Terex TLB 890 backhoe loader?

The Terex TLB 890 has a transport length of 6.22 meters, a transport width of 2.11 meters, and a transport height of 3.76 meters.

What are the undercarriage specifications of the Terex TLB 890 backhoe loader?

The Terex TLB 890 features an all-wheel drive system and comes equipped with VR 20 standard tyres.

What is the excavation performance of the Terex TLB 890 backhoe loader?

The Terex TLB 890 has a dredging depth of 4.5 meters and a maximum horizontal reach of 5.7 meters.

What is the maximum discharge height of the Terex TLB 890?

The Terex TLB 890 has a maximum discharge height of 3.58 meters.

What are the specifications of the primary work tool bucket on the Terex TLB 890?

The Terex TLB 890 has a bucket with a capacity of 1 cubic meter and a width of 2.3 meters.

How much is a Terex TLB 890 Backhoe loader (2012u20132017) worth?

The residual value of the Terex TLB 890 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
