PB 90 Palazzani PB 90 Specifications & Technical Data (2006—2017)

The Palazzani PB 90 is a backhoe loader manufactured by Palazzani from 2006 to 2017. It has a weight of 8.4 tons and a transport l…

The Palazzani PB 90 is a backhoe loader manufactured by Palazzani from 2006 to 2017. It has a weight of 8.4 tons and a transport length of 5.82 meters. The bucket capacity is 1.1 cubic meters, with a tear-out force of 75 kilonewtons. It can dredge up to a depth of 4.8 meters and has a bucket width of 2.2 meters. The maximum discharge height is 5.25 meters, and it can reach horizontally up to 5.3 meters. The transport width and height are both 2.2 meters and 3.5 meters respectively. The PB 90 is equipped with special features including a clamshell and outrigger stabilizers.

PB 90

Years of manufacture: 2006—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PB 90 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.4 t

Standard tyres: 16/70x24

Bucket width: 2.2 m

Bucket capacity: 1.1 m³

Drive: A

Transport length: 5.82 m

Transport width: 2.2 m

Transport height: 3.5 m

Tear-out force: 75 kN

Max. Reach horizontal: 5.3 m

Dredging depth: 4.8 m

Max. discharge height: 5.25 m

Model series: PB

Engine manuf.: Perkins

Engine type: 1104C-E44T

Engine power: 77 kW

Displacement: 4.4 l

Revolutions at max torque: 2400 rpm

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Palazzani PB 90 FAQ

When was the Palazzani PB 90 manufactured?

The Palazzani PB 90 was manufactured from 2006 to 2017.

How much does the Palazzani PB 90 weigh?

The Palazzani PB 90 weighs 8.4 tons.

What are the transport dimensions of the Palazzani PB 90 backhoe loader?

The Palazzani PB 90 has a transport length of 5.82 meters, a transport width of 2.2 meters, and a transport height of 3.5 meters.

What are the undercarriage specifications of the Palazzani PB 90 backhoe loader?

The Palazzani PB 90 features an all-wheel drive system and is equipped with standard tyres sized 16/70x24.

What are the excavation performance specifications of the Palazzani PB 90 backhoe loader?

The Palazzani PB 90 has a dredging depth of 4.8 meters and a maximum horizontal reach of 5.3 meters.

What is the tear-out force of the Palazzani PB 90 backhoe loader?

The Palazzani PB 90 backhoe loader has a tear-out force of 75 kN.

What is the maximum discharge height of the Palazzani PB 90 backhoe loader?

The Palazzani PB 90 backhoe loader has a maximum discharge height of 5.25 meters.

What are the specifications of the primary work tool on the Palazzani PB 90 backhoe loader?

The primary work tool of the Palazzani PB 90 has a bucket capacity of 1.1 cubic meters and a bucket width of 2.2 meters.
