PB 70.2 Palazzani PB 70.2 Specifications & Technical Data (2009—2014)

The Palazzani PB 70.2 is a backhoe loader manufactured by Palazzani from 2009 to 2014. It has a weight of 6.35 tons and a transpor…

The Palazzani PB 70.2 is a backhoe loader manufactured by Palazzani from 2009 to 2014. It has a weight of 6.35 tons and a transport length of 5.45 meters. The bucket capacity is 1 cubic meter, with a tear-out force of 65 kilonewtons. It can dredge up to a depth of 4.2 meters and has a bucket width of 2 meters. The maximum discharge height is 4.5 meters, and it has a maximum reach horizontal of 4.7 meters. The transport width is 2 meters and the transport height is 3.14 meters. This construction machine is equipped with special equipment including a clamshell and outrigger stabilizers.

PB 70.2

Years of manufacture: 2009—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PB 70.2 Palazzani

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 6.35 t

Standard tyres: 14.5x20

Bucket width: 2 m

Bucket capacity: 1 m³

Drive: A

Transport length: 5.45 m

Transport width: 2 m

Transport height: 3.14 m

Tear-out force: 65 kN

Max. Reach horizontal: 4.7 m

Dredging depth: 4.2 m

Max. discharge height: 4.5 m

Model series: PB

Engine manuf.: Perkins

Engine type: 1104D-44T

Engine power: 75 kW

More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: Yes
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Palazzani PB 70.2 FAQ

When was the Palazzani PB 70.2 manufactured?

The Palazzani PB 70.2 was manufactured from 2009 to 2014.

How much does the Palazzani PB 70.2 weigh?

The Palazzani PB 70.2 weighs 6.35 tons.

What are the transport dimensions of the Palazzani PB 70.2 backhoe loader?

The Palazzani PB 70.2 has a transport length of 5.45 meters, a transport width of 2 meters, and a transport height of 3.14 meters.

What are the undercarriage specifications of the Palazzani PB 70.2 backhoe loader?

The Palazzani PB 70.2 features an all-wheel drive system and standard tyres sized 14.5x20.

What is the excavation performance of the Palazzani PB 70.2 backhoe loader?

The Palazzani PB 70.2 has a dredging depth of 4.2 meters and a maximum horizontal reach of 4.7 meters.

What is the tear-out force of the Palazzani PB 70.2 backhoe loader?

The Palazzani PB 70.2 backhoe loader has a tear-out force of 65 kN.

What is the material handling capacity of the Palazzani PB 70.2 in terms of maximum discharge height?

The Palazzani PB 70.2 has a maximum discharge height of 4.5 meters.

What are the specifications of the primary work tool on the Palazzani PB 70.2 backhoe loader?

The primary work tool of the Palazzani PB 70.2 backhoe loader has a bucket capacity of 1 cubic meter and a bucket width of 2 meters.

How much is a Palazzani PB 70.2 Backhoe loader (2009u20132014) worth?

The residual value of the Palazzani PB 70.2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
