Technical specs - B95D TC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.03 t

Standard tyres: 12-16.5/19.5L-24

Bucket width: 2.248 m

Bucket capacity: 1.05 m³

Bucket capacity backhoe: 1 m³

Transport length: 7.159 m

Transport width: 2.318 m

Transport height: 2.862 m

Max. Reach horizontal: 6.313 m

Dredging depth: 5.627 m

Max. discharge height: 4.384 m

Model series: B

Engine manuf.: FPT

Engine type: F5BFL413B*B003

Engine power: 72 kW

Displacement: 3.4 l

Revolutions at max torque: 2200 rpm

Max. torque: 458 Nm

No. of cylinders: 4

Emission level: Tier 4 Final

More technical details, like: drive, tear-out force, tear-out force backhoe, travel speed, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: No
Grabber: Yes
Diesel particulate filter: Yes
Aircondition: Yes

New Holland B95D TC FAQ

When was the New Holland B95D TC manufactured?

The New Holland B95D TC was first produced in 2023.

How much does the New Holland B95D TC weigh?

The New Holland B95D TC weighs 8.03 tons.

What are the transport dimensions of the New Holland B95D TC backhoe loader?

The New Holland B95D TC has a transport length of 7.16 meters, a transport width of 2.32 meters, and a transport height of 2.86 meters.

What are the undercarriage specifications of the New Holland B95D TC backhoe loader?

The New Holland B95D TC backhoe loader comes with standard tyres sized 12-16.5/19.5L-24.

What is the excavation performance of the New Holland B95D TC backhoe loader?

The New Holland B95D TC has a dredging depth of 5.627 meters and a maximum horizontal reach of 6.313 meters.

What is the maximum discharge height of the New Holland B95D TC?

The New Holland B95D TC has a maximum discharge height of 4.38 meters.

What are the specifications of the primary work tools on the New Holland B95D TC backhoe loader?

The New Holland B95D TC has a front loader bucket with a capacity of 1.05 cubic meters and a width of 2.25 meters, and a backhoe bucket with a capacity of 1 cubic meter.
