TLB990 Mecalac TLB990 Specifications & Technical Data (2017—2026)

The Mecalac TLB990 is a backhoe loader manufactured by Mecalac since 2017. It has a weight of 8.76 tons and a transport length of …

The Mecalac TLB990 is a backhoe loader manufactured by Mecalac since 2017. It has a weight of 8.76 tons and a transport length of 6.14 meters. The bucket capacity is 1.2 cubic meters, with a tear-out force of 51.1 kN. The dredging depth is 5.64 meters, and the bucket width is 2.39 meters. The maximum discharge height is 3.42 meters, and the maximum reach horizontal is 6.95 meters. It has a travel speed of 39.5 km/h. The transport width and height are both 2.39 and 3.81 meters respectively. The backhoe bucket capacity is 0.58 cubic meters, with a tear-out force of 41.1 kN. It is equipped with outrigger stabilizers.

TLB990

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TLB990 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 8.76 t

Standard tyres: 440/80 R 24

Bucket width: 2.39 m

Bucket capacity: 1.2 m³

Bucket capacity backhoe: 0.58 m³

Transport length: 6.14 m

Transport width: 2.39 m

Transport height: 3.81 m

Tear-out force: 51.1 kN

Tear-out force backhoe: 41.1 kN

Max. Reach horizontal: 6.95 m

Dredging depth: 5.64 m

Max. discharge height: 3.42 m

Travel speed: 39.5 km/h

Model series: TLB

Engine manuf.: Perkins

Engine type: 1204E-E44TA

Engine power: 74.5 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

Max. torque: 450/1400 Nm

No. of cylinders: 4

Emission level: IIIA/Tier 4 i

More technical details, like: drive, dimension lxwxh, cylinder bore x stroke, backhoe type, engine manufacturer, engine model, aspiration, charged air cooling, exhaust gas recirculation, diesel oxidation catalyst, diesel particulate filter, selective catalytic reduction, rated speed, engine output - net, engine output - gross, torque rated speed, torque, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, width, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, dig depth - sae retracted dipper, dig depth - sae extended dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, dump height - multi-purpose, dump angle - multi-purpose, fuel tank, shovel capacity - standard general purpose, shovel capacity - multi-purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, shovel breakout - multi-purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

Mecalac TLB990 FAQ

When was the Mecalac TLB990 manufactured?

The Mecalac TLB990 was first produced in 2017.

How much does the Mecalac TLB990 weigh?

The Mecalac TLB990 weighs 8.76 tons.

What are the transport dimensions of the Mecalac TLB990 backhoe loader?

The Mecalac TLB990 has a transport length of 6.14 meters, a transport width of 2.39 meters, and a transport height of 3.81 meters.

What is the travel speed of the Mecalac TLB990 backhoe loader?

The Mecalac TLB990 backhoe loader has a travel speed of 39.5 km/h.

What are the undercarriage tyre specifications of the Mecalac TLB990 backhoe loader?

The Mecalac TLB990 is equipped with standard tyres sized 440/80 R 24.

What is the excavation performance of the Mecalac TLB990 backhoe loader?

The Mecalac TLB990 has a dredging depth of 5.64 meters and a maximum horizontal reach of 6.95 meters.

What are the tear-out forces of the Mecalac TLB990 backhoe loader?

The Mecalac TLB990 has a tear-out force of 51.1 kN and a backhoe tear-out force of 41.1 kN.

What is the material handling capacity of the Mecalac TLB990 in terms of maximum discharge height?

The Mecalac TLB990 has a maximum discharge height of 3.42 meters.

What are the specifications of the primary work tools on the Mecalac TLB990 backhoe loader?

The Mecalac TLB990 features a loader bucket with a capacity of 1.2 cubic meters and a width of 2.39 meters, as well as a backhoe bucket with a capacity of 0.58 cubic meters.
