TLB880 Mecalac TLB880 Specifications & Technical Data (2021—2026)

The Mecalac TLB880 is a backhoe loader manufactured by Mecalac since 2021. It has a weight of 8.06 tons and a transport length of …

The Mecalac TLB880 is a backhoe loader manufactured by Mecalac since 2021. It has a weight of 8.06 tons and a transport length of 6.14 meters. The bucket capacity is 1.2 cubic meters, with a tear-out force of 46 kilonewtons. The dredging depth is 5.7 meters, and the bucket width is 2.31 meters. The maximum discharge height is 3.37 meters, and the maximum reach horizontal is 7 meters. The travel speed is 40 kilometers per hour. The transport width is 2.39 meters, and the transport height is 3.75 meters. The backhoe has a bucket capacity of 0.58 cubic meters and a tear-out force of 42 kilonewtons. The special equipment includes outrigger stabilizers.

Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880
Backhoe Loaders Mecalac TLB880

Visit Mecalac live at

Technical specs - TLB880 Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.06 t
Standard tyres
12.5/80x18 / 16.9x28
Bucket width
2.31 m
Bucket capacity
1.2 m³
Bucket capacity backhoe
0.58 m³
Drive
A
Transport length
6.14 m
Transport width
2.39 m
Transport height
3.75 m
Tear-out force
46 kN
Tear-out force backhoe
42 kN
Max. Reach horizontal
7 m
Dredging depth
5.7 m
Max. discharge height
3.37 m
Travel speed
40 km/h
Model series
TLB
Engine manuf.
Perkins
Engine type
904J-E36TA
Engine power
74.4 kW
Displacement
3.621 l
Revolutions at max torque
2200 rpm
Max. torque
430/1500 Nm
No. of cylinders
4
Cylinder bore x stroke
98x120 mm
Emission level
V/Tier 4 f

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

Mecalac TLB880 FAQ

When was the Mecalac TLB880 manufactured?

The Mecalac TLB880 was first produced in 2021.

How much does the Mecalac TLB880 backhoe loader weigh?

The Mecalac TLB880 backhoe loader weighs 8.06 tons.

What are the transport dimensions of the Mecalac TLB880 backhoe loader?

The Mecalac TLB880 has a transport length of 6.14 meters, a transport width of 2.39 meters, and a transport height of 3.75 meters.

What is the travel speed of the Mecalac TLB880 backhoe loader?

The Mecalac TLB880 backhoe loader has a travel speed of 40 km/h.

What are the undercarriage specifications of the Mecalac TLB880 backhoe loader?

The Mecalac TLB880 features an all-wheel drive system and standard tyres sized 12.5/80x18 and 16.9x28.

What is the excavation performance of the Mecalac TLB880 backhoe loader?

The Mecalac TLB880 has a dredging depth of 5.7 meters and a maximum horizontal reach of 7 meters.

What are the tear-out forces of the Mecalac TLB880 backhoe loader?

The Mecalac TLB880 has a tear-out force of 46 kN and a backhoe tear-out force of 42 kN.

What is the maximum discharge height of the Mecalac TLB880?

The Mecalac TLB880 has a maximum discharge height of 3.37 meters.

What are the primary work tool specifications of the Mecalac TLB880 backhoe loader?

The Mecalac TLB880 has a bucket capacity of 1.2 cubic meters, a bucket width of 2.31 meters, and a backhoe bucket capacity of 0.58 cubic meters.

How much is a Mecalac TLB880 Backhoe loader (2021u20132025) worth?

The residual value of the Mecalac TLB880 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
