Komatsu WB92A Backhoe Loader Specs & Dimensions (1997 - 1998)

Technical specs - WB92A Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 7.58 t

Standard tyres: 16/70-20

Bucket capacity: 0.85 m³

Drive: A

Transport length: 5.95 m

Transport width: 2.1 m

Transport height: 3.35 m

Model series: WB

Engine manuf.: Perkins

Engine type: 4.236 T

Engine power: 70 kW

More technical details, like: bucket width, bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, dredging depth, max. discharge height, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: bucket width, bucket capacity backhoe, tear-out force, tear-out force backhoe, max. reach horizontal, dredging depth, max. discharge height, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, backhoe type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, engine output - gross, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, dig depth - sae retracted dipper, dig depth - sae extended dipper, reach from slew pivot - non-extending dipper, reach from slew pivot - retracted dipper, reach from slew pivot - extended dipper, loading height - non-extending dipper, loading height - retracted dipper, loading height - extended dipper, dump height - general purpose, dump angle - general purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Komatsu WB92A FAQ

When was the Komatsu WB92A manufactured?

The Komatsu WB92A was manufactured from 1997 to 1998.

How much does the Komatsu WB92A backhoe loader weigh?

The Komatsu WB92A backhoe loader weighs 7.58 tons.

What are the transport dimensions of the Komatsu WB92A backhoe loader?

The Komatsu WB92A has a transport length of 5.95 meters, a transport width of 2.1 meters, and a transport height of 3.35 meters.

What are the undercarriage specifications of the Komatsu WB92A backhoe loader?

The Komatsu WB92A backhoe loader features an all-wheel drive system and standard tyres sized 16/70-20.

What is the bucket capacity of the Komatsu WB92A backhoe loader?

The bucket capacity of the Komatsu WB92A backhoe loader is 0.85 cubic meters.

How much is a Komatsu WB92A Backhoe loader (1997u20131998) worth?

The residual value of the Komatsu WB92A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
