710L John Deere Construction 710L Specifications & Technical Data (2017—2026)

The John Deere Construction 710L is a backhoe loader that has been manufactured since 2017. It weighs 11.61 tons and has a transpo…

The John Deere Construction 710L is a backhoe loader that has been manufactured since 2017. It weighs 11.61 tons and has a transport length of 8.23 meters. The bucket capacity is 1.24 cubic meters, with a tear-out force of 73.6 kilonewtons. It can dredge up to a depth of 5.26 meters and has a bucket width of 2.46 meters. The maximum discharge height is 2.89 meters, and it has a maximum reach horizontal of 6.84 meters. The travel speed of this machine is 37.6 kilometers per hour. It has a transport width of 2.29 meters and a transport height of 2.97 meters. The backhoe bucket capacity is 0.31 cubic meters, with a tear-out force of 78.4 kilonewtons.

Backhoe Loaders John Deere Construction 710L

710L

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 710L John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11.61 t

Standard tyres: F: 15-19.5 R4 (12) R: 21L-28 R4 (18)

Bucket width: 2.46 m

Bucket capacity: 1.24 m³

Bucket capacity backhoe: 0.31 m³

Drive: A

Transport length: 8.23 m

Transport width: 2.29 m

Transport height: 2.97 m

Tear-out force: 73.6 kN

Tear-out force backhoe: 78.4 kN

Max. Reach horizontal: 6.84 m

Dredging depth: 5.26 m

Max. discharge height: 2.89 m

Travel speed: 37.6 km/h

Model series: L

Engine manuf.: John Deere

Engine type: 4045HT084

Engine power: 110 kW

Displacement: 4.5 l

Revolutions at max torque: 2240 rpm

Max. torque: 575/1400 Nm

No. of cylinders: 4

Emission level: Tier 4/EU IV

More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: No
Clamshell: No
Forklift utility: No
Grabber: No
Diesel particulate filter: No
Aircondition: No

Download datasheets (PDF)

John Deere Construction 710L FAQ

When was the John Deere Construction 710L manufactured?

The John Deere Construction 710L was first produced in 2017.

How much does the John Deere Construction 710L weigh?

The John Deere Construction 710L weighs 11.61 tons.

What are the transport dimensions of the John Deere Construction 710L backhoe loader?

The John Deere Construction 710L has a transport length of 8.23 meters, a transport width of 2.29 meters, and a transport height of 2.97 meters.

What is the travel speed of the John Deere Construction 710L backhoe loader?

The John Deere Construction 710L backhoe loader has a travel speed of 37.6 km/h.

What are the undercarriage specifications of the John Deere Construction 710L backhoe loader?

The John Deere Construction 710L features an all-wheel drive system with standard tyres sized Front: 15-19.5 R4 (12) and Rear: 21L-28 R4 (18).

What are the dredging depth and maximum horizontal reach of the John Deere Construction 710L backhoe loader?

The John Deere Construction 710L has a dredging depth of 5.26 meters and a maximum horizontal reach of 6.84 meters.

What are the tear-out forces of the John Deere Construction 710L backhoe loader?

The John Deere Construction 710L has a tear-out force of 73.6 kN and a backhoe tear-out force of 78.4 kN.

What is the maximum discharge height of the John Deere Construction 710L?

The John Deere Construction 710L has a maximum discharge height of 2.89 meters.

What are the bucket specifications of the John Deere Construction 710L backhoe loader?

The John Deere Construction 710L has a front bucket capacity of 1.24 cubic meters with a width of 2.46 meters, and a backhoe bucket capacity of 0.31 cubic meters.
