1260 B Huddig 1260 B Specifications & Technical Data (2008—2011)

Model rating
10,00 / 10

The Huddig 1260 B is a backhoe loader manufactured by Huddig from 2008 to 2011. It has a weight of 12.85 tons and a transport leng…

The Huddig 1260 B is a backhoe loader manufactured by Huddig from 2008 to 2011. It has a weight of 12.85 tons and a transport length of 8.63 meters. The bucket capacity is 2 cubic meters, with a tear-out force of 103 kilonewtons. It can dredge up to a depth of 4.9 meters and has a bucket width of 2.5 meters. The maximum discharge height is 3.5 meters, and it can reach a maximum horizontal distance of 6.53 meters. The transport width is 2.3 meters, and the transport height is 4.38 meters. It is equipped with outrigger stabilizers.

Backhoe Loaders Huddig 1260 B

Technical specs - 1260 B Huddig

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
12.85 t
Standard tyres
520/70x30
Bucket width
2.5 m
Bucket capacity
2 m³
Transport length
8.63 m
Transport width
2.3 m
Transport height
4.38 m
Tear-out force
103 kN
Max. Reach horizontal
6.53 m
Dredging depth
4.9 m
Max. discharge height
3.5 m
Model series
1260
Engine manuf.
Cummins
Engine type
QSB6.7
Engine power
116 kW
Displacement
6.7 l
Revolutions at max torque
1400 rpm
Emission level
III

More technical details, like: bucket capacity backhoe, drive, tear-out force backhoe, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, backhoe type, engine manufacturer, engine model, aspiration...

More technical details, like: bucket capacity backhoe, drive, tear-out force backhoe, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, backhoe type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, transmission type, number of travel speeds, drive - 2wd / 4wd, service brake type, length - roading, height - over cab, maximum height, width, ground clearance, width - standard shovel, stabiliser type, maximum dig depth - longest dipper, dig depth - sae, reach from slew pivot - non-extending dipper, loading height - non-extending dipper, dump height - general purpose, dump angle - general purpose, fuel tank, shovel capacity - standard general purpose, bucket tearout - non-extending dipper, dipper tearout - non-extending dipper, shovel breakout - general purpose, operating weight are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
No
Forklift utility
No
Grabber
No
Diesel particulate filter
No
Aircondition
No

Download datasheets (PDF)

Huddig 1260 B FAQ

When was the Huddig 1260 B manufactured?

The Huddig 1260 B was manufactured from 2008 to 2011.

How much does the Huddig 1260 B backhoe loader weigh?

The Huddig 1260 B backhoe loader weighs 12.85 tons.

What are the transport dimensions of the Huddig 1260 B backhoe loader?

The Huddig 1260 B has a transport length of 8.63 meters, a transport width of 2.3 meters, and a transport height of 4.38 meters.

What are the undercarriage tyre specifications of the Huddig 1260 B backhoe loader?

The Huddig 1260 B backhoe loader is equipped with standard tyres sized 520/70x30.

What are the excavation performance specifications of the Huddig 1260 B backhoe loader?

The Huddig 1260 B has a dredging depth of 4.9 meters and a maximum horizontal reach of 6.53 meters.

What is the tear-out force of the Huddig 1260 B backhoe loader?

The Huddig 1260 B backhoe loader has a tear-out force of 103 kN.

What is the maximum discharge height of the Huddig 1260 B?

The Huddig 1260 B has a maximum discharge height of 3.5 meters.

What are the specifications of the primary work tool bucket on the Huddig 1260 B?

The primary work tool bucket of the Huddig 1260 B has a capacity of 2 cubic meters and a width of 2.5 meters.
