710 B John Deere Construction 710 B Specifications & Technical Data (1985—1988)

The John Deere Construction 710 B is a backhoe loader manufactured from 1985 to 1988. It has a weight of 10.2 tons and a transport…

The John Deere Construction 710 B is a backhoe loader manufactured from 1985 to 1988. It has a weight of 10.2 tons and a transport length of 8.13 meters. The bucket capacity is 1.15 cubic meters, with a tear-out force of 47.1 kilonewtons. It can dredge up to a depth of 6.93 meters and has a bucket width of 2.34 meters. The maximum discharge height is 4.57 meters, and it has a maximum reach horizontal of 9.5 meters. The travel speed of this backhoe loader is 31.4 kilometers per hour. It has a transport width of 2.235 meters and a transport height of 4.2 meters. Additionally, it is equipped with special equipment including a diesel particulate filter, forklift utility, and outrigger stabilizers. The backhoe bucket capacity is 0.22 cubic meters, and it has a tear-out force of 60 kilonewtons.

Backhoe Loaders John Deere Construction 710 B

710 B

Years of manufacture: 1985—1988

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 710 B John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.2 t

Standard tyres: F: 14.5/75-16.1 10 PR F3 R: 21L-24 16 PR R4

Bucket width: 2.34 m

Bucket capacity: 1.15 m³

Bucket capacity backhoe: 0.22 m³

Transport length: 8.13 m

Transport width: 2.235 m

Transport height: 4.2 m

Tear-out force: 47.1 kN

Tear-out force backhoe: 60 kN

Max. Reach horizontal: 9.5 m

Dredging depth: 6.93 m

Max. discharge height: 4.57 m

Travel speed: 31.4 km/h

Model series: B

Engine manuf.: John Deere

Engine type: 6329T

Engine power: 78 kW

Displacement: 5.392 l

Max. torque: 389 Nm

No. of cylinders: 6

Cylinder bore x stroke: 102x110 mm

More technical details, like: drive, dimension lxwxh, revolutions at max torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers: Yes
Clamshell: No
Forklift utility: Yes
Grabber: No
Diesel particulate filter: Yes
Aircondition: No

Download datasheets (PDF)

John Deere Construction 710 B FAQ

When was the John Deere Construction 710 B manufactured?

The John Deere Construction 710 B was manufactured from 1985 to 1988.

How much does the John Deere Construction 710 B weigh?

The John Deere Construction 710 B weighs 10.2 tons.

What are the transport dimensions of the John Deere Construction 710 B backhoe loader?

The John Deere Construction 710 B has a transport length of 8.13 meters, a transport width of 2.24 meters, and a transport height of 4.2 meters.

What is the travel speed of the John Deere Construction 710 B backhoe loader?

The John Deere Construction 710 B backhoe loader has a travel speed of 31.4 km/h.

What are the undercarriage specifications of the John Deere Construction 710 B backhoe loader?

The John Deere Construction 710 B is equipped with standard tyres: Front tyres are 14.5/75-16.1 10 PR F3 and Rear tyres are 21L-24 16 PR R4.

What are the dredging depth and maximum horizontal reach of the John Deere Construction 710 B backhoe loader?

The John Deere Construction 710 B has a dredging depth of 6.93 meters and a maximum horizontal reach of 9.5 meters.

What are the tear-out forces of the John Deere Construction 710 B backhoe loader?

The John Deere Construction 710 B has a tear-out force of 47.1 kN and a backhoe tear-out force of 60 kN.

What is the material handling capacity of the John Deere Construction 710 B in terms of discharge height?

The John Deere Construction 710 B has a maximum discharge height of 4.57 meters.

What are the specifications of the primary work tool on the John Deere Construction 710 B backhoe loader?

The John Deere Construction 710 B features a bucket with a capacity of 1.15 cubic meters and a width of 2.34 meters, and its backhoe bucket has a capacity of 0.22 cubic meters.

How much is a John Deere Construction 710 B Backhoe loader (1985u20131988) worth?

The residual value of the John Deere Construction 710 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
