610 C John Deere Construction 610 C Specifications & Technical Data (1986—2021)
Technical specs - 610 C John Deere Construction
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 7.4 t
- Standard tyres
- F: 11L-16 12 PR F3 R: 19.5L-24 10 PR R4
- Bucket width
- 2.34 m
- Bucket capacity
- 1 m³
- Bucket capacity backhoe
- 0.08 m³
- Transport length
- 7.11 m
- Transport width
- 2.185 m
- Transport height
- 3.73 m
- Tear-out force
- 43.1 kN
- Tear-out force backhoe
- 48.9 kN
- Max. Reach horizontal
- 7.21 m
- Dredging depth
- 6.22 m
- Max. discharge height
- 4.7 m
- Travel speed
- 31.3 km/h
- Model series
- C
- Engine manuf.
- John Deere
- Engine type
- 4-276T
- Engine power
- 75 kW
- Displacement
- 4.524 l
- Max. torque
- 385 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 106.5x127 mm
More technical details, like: drive, dimension lxwxh, revolutions at max torque, emission level are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
Yes
- Clamshell
-
No
- Forklift utility
-
Yes
- Grabber
-
No
- Diesel particulate filter
-
Yes
- Aircondition
-
No
