410L John Deere Construction 410L Specifications & Technical Data (2017—2026)
Technical specs - 410L John Deere Construction
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8.07 t
- Standard tyres
- F:12.5/80-18 R4 (10) R: 21L-24 R4 (12)
- Bucket width
- 2.35 m
- Bucket capacity
- 1 m³
- Bucket capacity backhoe
- 0.21 m³
- Drive
- A
- Transport length
- 7.43 m
- Transport width
- 2.18 m
- Transport height
- 2.87 m
- Tear-out force
- 47.3 kN
- Tear-out force backhoe
- 69.9 kN
- Max. Reach horizontal
- 6.02 m
- Dredging depth
- 4.83 m
- Max. discharge height
- 2.68 m
- Travel speed
- 40 km/h
- Model series
- L
- Engine manuf.
- John Deere
- Engine type
- 4045HT083
- Engine power
- 84 kW
- Displacement
- 4.5 l
- Revolutions at max torque
- 2244 rpm
- Max. torque
- 447/1400 Nm
- No. of cylinders
- 4
- Emission level
- Tier 4/EU IV
More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
No
- Clamshell
-
No
- Forklift utility
-
No
- Grabber
-
No
- Diesel particulate filter
-
No
- Aircondition
-
No
