410 D John Deere Construction 410 D Specifications & Technical Data (1991—1997)

The John Deere Construction 410 D is a backhoe loader manufactured from 1991 to 1997. It has a weight of 7.075 tons and a transpor…

The John Deere Construction 410 D is a backhoe loader manufactured from 1991 to 1997. It has a weight of 7.075 tons and a transport length of 7.14 meters. The bucket capacity is 0.76 cubic meters, with a tear-out force of 44.5 kN. It can dredge up to a depth of 4.67 meters and has a bucket width of 2.34 meters. The maximum discharge height and reach horizontal are both 3.61 meters. It has a travel speed of 41.2 km/h. The transport width is 2.34 meters and the transport height is 3.48 meters. The backhoe has a bucket capacity of 0.07 cubic meters and a tear-out force of 52 kN. It is equipped with a diesel particulate filter and has special equipment including forklift utility and outrigger stabilizers.

Backhoe Loaders John Deere Construction 410 D

Technical specs - 410 D John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.075 t
Standard tyres
F: 11L-15 10 PR F3 R: 17.5-24 10 PR R4
Bucket width
2.34 m
Bucket capacity
0.76 m³
Bucket capacity backhoe
0.07 m³
Transport length
7.14 m
Transport width
2.34 m
Transport height
3.48 m
Tear-out force
44.5 kN
Tear-out force backhoe
52 kN
Max. Reach horizontal
3.61 m
Dredging depth
4.67 m
Max. discharge height
3.61 m
Travel speed
41.2 km/h
Model series
D
Engine manuf.
John Deere
Engine type
4045D
Engine power
60 kW
Displacement
4.524 l
Max. torque
344 Nm
No. of cylinders
4

More technical details, like: drive, dimension lxwxh, revolutions at max torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket

Special equipment

Outrigger stabilisers
Yes
Clamshell
No
Forklift utility
Yes
Grabber
No
Diesel particulate filter
Yes
Aircondition
No

Download datasheets (PDF)

John Deere Construction 410 D FAQ

When was the John Deere Construction 410 D manufactured?

The John Deere Construction 410 D was manufactured from 1991 to 1997.

How much does the John Deere Construction 410 D weigh?

The John Deere Construction 410 D weighs 7.08 tons.

What are the transport dimensions of the John Deere Construction 410 D backhoe loader?

The John Deere Construction 410 D has a transport length of 7.14 meters, a transport width of 2.34 meters, and a transport height of 3.48 meters.

What is the travel speed of the John Deere Construction 410 D backhoe loader?

The John Deere Construction 410 D backhoe loader has a travel speed of 41.2 km/h.

What are the undercarriage specifications of the John Deere Construction 410 D backhoe loader?

The John Deere Construction 410 D is equipped with standard tyres: Front tyres are 11L-15 10 PR F3 and Rear tyres are 17.5-24 10 PR R4.

What are the dredging depth and maximum horizontal reach of the John Deere Construction 410 D backhoe loader?

The John Deere Construction 410 D has a dredging depth of 4.67 meters and a maximum horizontal reach of 3.61 meters.

What are the tear-out forces of the John Deere Construction 410 D backhoe loader?

The John Deere Construction 410 D has a tear-out force of 44.5 kN and a tear-out force backhoe of 52 kN.

What is the material handling capacity of the John Deere Construction 410 D in terms of discharge height?

The John Deere Construction 410 D has a maximum discharge height of 3.61 meters.

What are the primary work tool specifications of the John Deere Construction 410 D backhoe loader?

The John Deere Construction 410 D features a bucket capacity of 0.76 cubic meters, a bucket width of 2.34 meters, and a backhoe bucket capacity of 0.07 cubic meters.
