Technical specs - 3CX SM JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8.1 t
- Standard tyres
- 12.5x18-10/18.4x26-12
- Bucket width
- 2.35 m
- Bucket capacity
- 1 m³
- Drive
- A
- Transport length
- 5.62 m
- Transport width
- 2.35 m
- Transport height
- 3.61 m
- Tear-out force
- 53.3 kN
- Max. Reach horizontal
- 5.37 m
- Dredging depth
- 4.24 m
- Max. discharge height
- 2.74 m
- Model series
- CX
- Engine manuf.
- JCB
- Engine type
- EcoMax
- Engine power
- 68 kW
- Displacement
- 4.4 l
- No. of cylinders
- 4
- Emission level
- IV
More technical details, like: bucket capacity backhoe, tear-out force backhoe, travel speed, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
No
- Clamshell
-
No
- Forklift utility
-
No
- Grabber
-
No
- Diesel particulate filter
-
No
- Aircondition
-
No
Download datasheets (PDF)
JCB 3CX SM FAQ
How much does the JCB 3CX SM backhoe loader weigh?
What are the transport dimensions of the JCB 3CX SM backhoe loader?
What are the undercarriage specifications of the JCB 3CX SM backhoe loader?
What is the excavation performance of the JCB 3CX SM backhoe loader?
What is the tear-out force of the JCB 3CX SM backhoe loader?
What is the maximum discharge height for material handling of the JCB 3CX SM backhoe loader?
What are the specifications of the primary work tool bucket on the JCB 3CX SM?
How much is a JCB 3CX SM Backhoe loader (2017u20132020) worth?
Events
Visit JCB live at
.jpg){kind=logo}
Machine inspection
Ask for inspection of your JCB 3CX SM from experts
Mevas is an international operating inspection service for used heavy machinery. Construction machinery inspectors are available in more than 20 countries.
Use this service to minimise the risk when buying used equipment. An inspection by Mevas costs less than repairing a defective hydraulic cylinder.
Provided by:
Buy & Rent
Compare JCB 3CX SM with similar Backhoe Loaders
.jpg)
JCB 3CX SM
- Weight:
- 8.1 t
- Standard tyres:
- 12.5x18-10/18.4x26-12
- Bucket width:
- 2.35 m
- Bucket capacity:
- 1 m³
John Deere Construction 310L
- Weight:
- 6.65 t
- Standard tyres:
- F:12.5/80-18 F3 (12) R: 19.5-24 R4 (12)
- Bucket width:
- 2.18 m
- Bucket capacity:
- 0.77 m³
New Holland 655 D
- Weight:
- 7.52 t
- Standard tyres:
- 16.5/85-28
- Bucket capacity:
- 1 m³
Hydrema H 906 E-ESD
- Weight:
- 9.2 t
- Standard tyres:
- 500/70x28
- Bucket width:
- 2.55 m
- Bucket capacity:
- 1.4 m³
Terex-Fermec 760
- Weight:
- 8.2 t
- Standard tyres:
- 16.9x30
- Bucket capacity:
- 1 m³
