3CX SM JCB 3CX SM Specifications & Technical Data (2017—2020)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit JCB live at
.jpg){kind=logo}
Technical specs - 3CX SM JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 8.1 t
- Standard tyres
- 12.5x18-10/18.4x26-12
- Bucket width
- 2.35 m
- Bucket capacity
- 1 m³
- Bucket capacity backhoe
- 0.26 m³
- Drive
- A
- Transport length
- 5.62 m
- Transport width
- 2.35 m
- Transport height
- 3.61 m
- Tear-out force
- 64.62 kN
- Tear-out force backhoe
- 62.01 kN
- Max. Reach horizontal
- 5.37 m
- Dredging depth
- 4.24 m
- Max. discharge height
- 2.74 m
- Travel speed
- 40 km/h
- Model series
- CX
- Engine manuf.
- JCB
- Engine type
- EcoMax
- Engine power
- 68 kW
- Displacement
- 4.4 l
- No. of cylinders
- 4
- Emission level
- IV
More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, standard shovel, rear with backhoe and standard bucket
Special equipment
- Outrigger stabilisers
-
No
- Clamshell
-
No
- Forklift utility
-
No
- Grabber
-
No
- Diesel particulate filter
-
No
- Aircondition
-
No
Download datasheets (PDF)
JCB 3CX SM FAQ
How much does the JCB 3CX SM weigh?
What are the transport dimensions of the JCB 3CX SM backhoe loader?
What is the travel speed of the JCB 3CX SM backhoe loader?
What are the undercarriage specifications of the JCB 3CX SM backhoe loader?
What is the excavation performance of the JCB 3CX SM backhoe loader?
What are the tear-out forces of the JCB 3CX SM backhoe loader?
What is the material handling capacity of the JCB 3CX SM in terms of maximum discharge height?
What are the bucket specifications of the JCB 3CX SM backhoe loader?
How much is a JCB 3CX SM Backhoe loader (2017u20132020) worth?
